Fire-Lite Communication Module ANN-LC

Key Features

• Each FACP (main MS-9050UD and remote panels) requires its own ANN-LC module
• Up to 16 remote panels (MS-9050UD and MS-9200UDLS)
• Fiber optic panel to panel connections to avoid potential ground faults or lightning strike issues
• Main panel communicates up to 50 points / 20 zones to the Central Station for the MS-9050UD and 198 points / 99 zones for the MS-9200UDLS
• Connects to the ANN-BUS of the fire panel and requires minimal programming
• Class B or Class A operation for survivability
• Each panel requires a unique "node" address that is assigned in programming

The Fire-Lite Alarms by Honeywell ANN-LC Communication Module, known as Lite-Connect, transforms the MS9050UD into a central station communicator for multiple fire alarm control panels. This innovative fiber module enables building owners to streamline central station communications onto a single panel, reducing the need for multiple phone lines. By utilizing fiber-optic technology, the MS9050UD seamlessly transmits comprehensive system information to the central station, while mitigating ground fault issues and lightning strike damage. For optimal performance, it is recommended to avoid using node address settings 10 or above with the IPGSM-DP(C) or IPGSM-COM Commercial Fire Communicator, although no restrictions apply to the IPGSM-4G(C).
