~$500.00
VIEW AVAILABILITY ON EBAY
Kidde Fire Alarm Control Panel FX-5RD
- Available in 5, and 10 zone (IDC) models
- CleanMe feature provides remote annunciation of a dirty detector
- Automatic drift compensation with select detectors reduces false alarms and extends dust life
- Listed to ANSI/UL 864 9th Edition
- Models with fully integrated upload/download DACT enables PC programming
- Zone or NAC pairs convertible to single Class A circuits
- Combination Waterflow and Supervisory IDCs
- NACs programmable by zone and individually selectable for notification appliances, continuous, temporal outputs, or coded
- Front panel programmable simplifies installation and servicing
- Precision synchronization with compatible notification appliances and optional audible silence over two wires
Key Features
Introducing the Kidde Commercial FX-5RD Fire Alarm Control Panel, a top-of-the-line conventional fire alarm system with 5-zone capabilities. This system boasts optional integrated upload/download DACT, intelligent/analog type detector features, serial annunciator modules, and remote relay modules for enhanced safety and control. Kidde's FACPs and components are rigorously tested and approved, meeting the 9th edition of the ANSI/UL 864 standard as well as CSFM/FDNY regulations. Trust Kidde for reliable and compliant fire safety solutions.
Technical Specifications
| Brand Name | Kidde Commercial |
|---|---|
| Manufacturer | Carrier |
| Manufacturer Part Number | FX-5RD |
| Product Model | FX-5RD |
| Product Name | 5 Zone Panel with Dialer Red 120VAC Power Source, 24VDC Output |
| Product Series | FX |
| Product Type | Fire Alarm Control Panel |
| Connectivity Technology | Wired |
| Number of Relays Supported | 9 |
| Number of Standard Zones | 5 |
| Number of Zones Supported | 10 |
| Panel Control Type | Conventional |
| Display Type | LCD |
| ADI Part Number Replaces | ED-EFSC302GD, ED-EFSC302RD, ED-EFSC502GD |
| Model Number Replaces | E-FSC302GD, E-FSC302RD, E-FSC502GD |
| Color | Red |
| Input Voltage | 120V AC, 24V DC |
| Features | Automatic drift compensation with select detectors reduces false alarms and extends dust life Listed to ANSI UL 864 9th Edition, Available in 5 and 10 zone (IDC) models, CleanMe feature provides remote annunciation of a dirty detector, Combination Waterflow and Supervisory IDCs NACs programmable by zone and individually selectable for notification appliances, continuous, temporal outputs, or coded, Conventional Fire Alarm Systems, Front panel programming simplifies installation and servicing Precision synchronization with compatible notification appliances and optional audible silence over two wires, Models with fully integrated upload/download DAT enables PC programming, On-board relays for Alarm, Supervisory and Trouble, One-Person walk-test (audible or silent), Optional City Tie and Reverse Polarity Modules, Optional serial bus relay modules are programmable for Common, Zone, or Matrix activation, Optional serial bus remote annunciator family, Trim ring available for semi-flush mounting, Zone or NAC pairs convertible to single Class A Circuits |
