Eaton Temperature Sensor HD1

Key Features

• Zone 0, Zone 1 and Zone 2 use
• ATEX certified: EExd IIB T3/T6, Exd IIC T6, EExem II T4/T6, Ex ia IIC T4/T6
• IECEx certified: Ex ia IIC T4/T6 Ga
• UL listed for USA and Canada: Class I, Div 2, Groups A, B, C D
• TR CU certified
• CQST certified
• CCOE certified
• SIL 2 certified
• IP66 & IP67
• Certified temperature: 20ºC to +125ºC (Exd), -20ºC to +55ºC (Exem/UL), -55ºC to +55ºC (Exia)

The Eaton HD1 Temperature Sensor is a reliable heat detector designed for hazardous environments. Ideal for fire alarm and suppression systems in a variety of applications such as paint spray booths, turbine rooms, and flammable material stores in industries like oil & gas and petrochemical. Featuring a Fenwal rate-compensated detector and sturdy all-stainless steel construction, it can be mounted in a type SM87 marine grade alloy enclosure for Exd version or JB10 corrosion-free GRP enclosure for Ex ia, Ex em/UL versions. The sensor's contact closes at the alarm temperature for quick response in critical situations.

Technical Specifications
