Fire-Lite Alarm Control Panel Monitor Module MMF-301
- 15-32V DC
- Supervises a Style B (Class B) circuit of dry-contact input devices
- Compact design allows mounting in a single-gang box behind the device it monitors
- Supervises IDC wiring and connection of external power source.
- High noise (EMF/RFI) immunity.
- SEMS screws with clamping plates for ease of wiring.
- Direct-dial entry entry of address: 01 – 159 on MS-9600 series panels, 01 – 99 on other compatible systems.
- LED flashes during normal operation.
- LED latches ste
Key Features
The Fire-Lite Alarms by Honeywell MMF-301 Alarm Control Panel Monitor Module is a compact and efficient solution for supervising a Style B (Class B) circuit of dry-contact input devices. With dimensions of just 1.3" H x 2.75" W x 0.65" D, this miniature monitor module can be easily mounted in a single-gang box behind the device it is monitoring. Ensure optimal safety and functionality with the MMF-301 from Fire-Lite Alarms by Honeywell.
Technical Specifications
| Brand Name | Fire-Lite Alarms by Honeywell |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | MMF-301 |
| Product Model | MMF-301 |
| Product Name | MMF-301 Monitor Module |
| Product Series | MMF |
| Product Type | Alarm Control Panel Monitor Module |
| Device Supported | Control Panel |
| Maximum Operating Temperature | 120.2°F (49°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Depth | 0.7" |
| Height | 1.3" |
| Width | 2.8" |
| Input Voltage | 32V DC |
| Country of Origin | MX |
