Fire-Lite Fire Alarm Control Panel MRP-2001
- Resettable and non-resettable output power
- Real-time clock or calendar with daylight savings time control
- Built-in Programmer
Key Features
Enhance fire safety in commercial, industrial, and institutional buildings with the Fire-Lite Alarms by Honeywell MRP-2001 Fire Alarm Control Panel. This six-zone FACP offers reliable fire detection and protection for water-based releasing applications. Compatible with System Sensor's i3 detectors, it ensures prompt maintenance alerts and supervisory signals for optimal performance. With programmable output circuits, dual hazard operation, and cross-zone capability, the MRP-2001 is a versatile and essential addition to any fire safety system. Discover its full range of features and benefits in the FireLite Device Compatibility Document.
Technical Specifications
| Brand Name | Fire-Lite Alarms by Honeywell |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | MRP2001 |
| Product Line | MRP |
| Product Model | MRP-2001 |
| Product Name | MRP-2001 Fire Alarm Control Panel |
| Product Series | MRP |
| Product Type | Fire Alarm Control Panel |
| Application/Usage | Commercial |
| Number of Events Log | 256 |
| Number of Standard Zones | 6 |
| Number of Zones Supported | 6 |
| Panel Control Type | Conventional |
| Battery Built-in | Yes |
| Maximum Operating Humidity | 0.93 |
| Display Type | LCD |
| Input Voltage | 120V AC |
| Limited Warranty | 3-Year |
| Compatibility | System Sensor i3 Series DetectorsFire-Lite:Smoke DetectorsPull StationsWaterflow DevicesTamper Switches |
| Country of Origin | US |
| Features | 24 volt DC operation, Adjustable waterflow discharge timer and two soak timers Cross-zone (double-interlock) capability, ANN-BUS for connection to optional devices 80-character LCD display (backlit), Automatic battery charger with charger supervision, Built-in Programmer, Designed for sprinkler standards NFPA 13, 15 and 16 Dual hazard operation, Disable/Enable control per input zone and output zone, Extensive transient protection, FM Approved, Four programmable Style Y (Class B) output circuits Strobe Synchronization, History log with 256 event storage, Listed to UL Standard 864, 9th edition, Low AC voltage sense, Piezo sounder for alarm, trouble and supervisory, Real-time clock/calendar with daylight savings time control, Resettable and non-resettable output power, Six programmable Style B (Class B) IDCs (Initiating Device Circuit) System Sensor i3 series detectors compatible, Three programmable Form-C relays 7.0 amps total 24 VDC output current |
| Package Contents | MRP-2001 Fire Alarm Control PanelBackboxPower SupplyTechnical ManualInstruction Sheet |
