Potter Smoke Detector PAD300-PD
- Low profile, less than 2" with the base
- LED alarm indicator
- UUKL Listed for Smoke Control
- Wide selectable sensitivity range of 1.1 to 3.5% per foot
- Detector communicates sensitivity to control panel
- UL listed smoke calibration and sensitivity
- Simple DIP switch address setting, no programming tool required
- Magnetic test switch
- UL268 7th edition compliant
Key Features
Introducing the PAD300-PD Photoelectric Smoke Detector by Potter Electric Signal, LLC. This Analog Addressable smoke detector is designed to seamlessly integrate with fire alarm control panels utilizing the Potter Addressable Device (PAD) protocol. Crafted from durable off-white plastic, this low profile smoke detector offers a wide sensitivity range of 1.1 to 3.5% per foot and is UL listed. Equipped with drift compensation and a built-in dirty detector warning, the PAD300-PD ensures reliable performance. Easily addressable via DIP switches at the rear, this detector can be conveniently programmed in the field without the need for special tools, making it a versatile and efficient choice for life safety systems.
Technical Specifications
| Brand Name | Potter Electric Signal, LLC |
|---|---|
| Manufacturer | Potter Electric Signal, LLC |
| Manufacturer Part Number | PAD300PD |
| Package Length | 3.930000000 |
| Product Model | PAD300-PD |
| Product Name | Photoelectric Smoke Detector |
| Product Series | PAD300 |
| Product Type | Smoke Detector |
| Addressable | Yes |
| Connectivity Technology | Wired |
| Detectable Medium | Smoke |
| Sensing Technology | Photoelectric |
| Sensor Type | Photoelectric, Thermal |
| UL Listed | Yes |
| Status Indicators | Yes |
| Color | White |
| Form Factor | Ceiling Mount |
| Height | 1.4" |
| Weight | 3.21oz |
| Input Voltage | 24V DC |
| Diameter | 3.9" |
| Mount Type | Ceiling Mount |
| Limited Warranty | 5-Year |
| Certifications | UL 268 |
| Compatibility | Fire alarm control panels |
| Country of Origin | CH |
