Kidde Input Module GSA-CT2
- Multiple applications
- GSA-CT1HT rated for high temperature environments
- Plug-in (UIO) or standard 1-gang mount
- Automatic device mapping
- Electronic addressing
- Stand-alone operation
- Ground fault detection by address
Key Features
The Kidde Commercial GSA-CT2 Input Module is an intelligent analog addressable device designed to connect one or two Class B normally-open Alarm, Supervisory, or Monitor type dry contact Initiating Device Circuits (IDC). The module's functionality is customizable through a unique "personality code" selected by the installer and downloaded from the Signature loop controller during system setup. By converting analog information from connected initiating devices into digital signals, the on-board microprocessor can accurately determine whether an alarm should be triggered. With a convenient mount to standard North American 1-gang electrical boxes, the GSA-CT2 is perfect for single-module installations and seamlessly integrates into the UIO family of plug-in Signature Series modules for easy setup and flexibility.
Technical Specifications
| Brand Name | Kidde Commercial |
|---|---|
| Manufacturer | Carrier |
| Manufacturer Part Number | GSA-CT2 |
| Product Model | GSA-CT2 |
| Product Name | Dual Input Module - UL/ULC Listed |
| Product Series | GSA |
| Product Type | Input Module |
| Device Supported | Control Panel |
| Maximum Operating Temperature | 120.2°F (49°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Input Voltage | 19V DC |
| Country of Origin | MX |
