Potter Waterflow Switch VSR-SG

Key Features

• Assembled in USA
• 0-90 second field replaceable time delay retard
• Easy to read retard time delay adjustment knob
• Maximum Surge: 18 FPS (5.5 m/s)
• Contact Ratings:
• Two sets of SPDT (Form C)
• 10.0 Amps at 125/250VAC
• 2.0 Amps at 30VDC Resistive
• 10 mAmps min. at 24VDC
• Conduit Entrance: One opening for ½" conduit. Individual switch compartments suitable for dissimilar voltages.

Introducing the Potter Electric Signal, LLC VSR-SG Waterflow Switch, a vane type solution designed for wet sprinkler systems utilizing CPVC plastic fittings from leading manufacturers like Tyco, Nibco, Victaulic, Ipex, and Spears Manufacturing Company. Compatible with pipe sizes ranging from 1" to 2", this model features two single pole, double throw, snap action switches and an adjustable pneumatic retard for instant recycling. With a flow activation threshold of 10 GPM (38 LPM) downstream, the VSR-SG ensures reliable performance while offering easy installation in tight spaces with its union feature. Upgrade your fire safety system with this cutting-edge waterflow switch today.

Technical Specifications
